Fast mounting to save time
Automatic feeding with silent technology
Easy to operate with large touch screen
Powerful heating，strong pressure，fully soaking and holding samples
Penetration-60 (P-60 for short) is a highly adaptable hot mounter. With fast mounting speed and superior sample infiltration protection, the mounting quality and production capacity are doubled. The high adaptability of the equipment can meet the needs of different diameters, different resin powders, and different cooling methods. The equipment has three unique skills: strong heating, surging pressurization, and extremely fast cooling, which can compress the mounting process time within 5 minutes. The appearance is sharp and angular, rigid but round which was designed by the master designer. It is a combination of square and round, low-key but elegant.
Powerful heating, strong pressure and rapid cooling.
High-power integrated heating technology greatly improves thermal efficiency; conductive heating ensures uniform heating of the resin;
Equipped with a high-performance hydraulic power system, it provides stable and high-intensity pressure throughout the entire process;
It can quickly transfer sample heat by ultra-large refrigerant contact area and multi-dimensional heat exchange technology；
The mounting equipment with three unique skills can compress the inlay process time within 6 minutes.
.jpg)
Human-machine interface
Large touch screen, clear operation options, intuitive display of data such as temperature, pressure, time, etc., ensuring full flexibility of sample mounting.
Data methods
The system contains recommended parameters for a variety of common resins.Users can also customize 5 to 10 different mounting methods to ensure faster turnover, minimum error rate and shorter setup time.
Automatic feeding system
The equipment has an extended automatic feeding function, quantitative feeding and one-click completion.
Single-tube and double-tube can be chosen
Standard equipped in mainstream diameter mounting tubes (Ф25mm, Ф30mm, Ф40mm, Ф50mm), double tubes can work independently in combination on the left and right and meet the needs of samples of different diameters.
Meet the mounting needs of all resin powders
Meet the mounting needs of various resins on the market including wood powder phenolic resin, carbon powder phenolic resin, iron powder acrylic resin and mineral powder epoxy resin.
Meet the requirements of various cooling methods
The equipment provides different types of cooling modes such as air cooling, slow cooling, fast cooling and rapid cooling.The cooling speed and cooling time can be freely set.
Penetration-60 is a highly efficient fully automatic double-station hot mounting
machine. High-power integrated heating technology greatly improves thermal
efficiency and can reach the set temperature in a very short time;
High-performance hydraulic power system provides stable and high-intensity
pressure throughout the entire process; It can quickly transfer sample heat
by ultra-large refrigerant contact area and multi-dimensional heat
exchange technology. Compressing the mounting process time within 5
minutes. Fast mounting and good-looking are the best interpretations
of this machine.
Demo
Penetration-60 Fully Automatic Double Station Hot Mounting Machine
The equipment has three unique skills: strong heating, surging pressurization, and extremely fast cooling, which can compress the mounting process time within 5 minutes. The appearance is sharp and angular, rigid but round which was designed by the master designer. It is a combination of square and round, low-key but elegant.
.png)
PDF
下载
The customer's agreement is truly good! Whether it's products or services, the genuine feedback from customers is the source of our continuous improvement. Customer recognition is our unparalleled glory.
Truer has experience engineers in technology service and experts who has abundant sample preparation skills and can provide the customized service to you.We will provide the professional preparation skill and operating proposals also can install and debug on-site.Warranty is one year for the equipment and lifetime maintenance.The technical support online and skills training can be provided annual.
